🔮 Liquid Glass JS (@ozcanyldzhn/liquid-glass-js)

Framework-agnostic, ultra-realistic iOS 26 Liquid Glass optical displacement effect for modern web applications.

⚡ Live Demo • Vue 3 & Nuxt • React & Next.js • Vanilla HTML/JS • Physics Studio • API Reference

---

✨ Features

• 💎 Real-time Fluid Optical Physics: Authentic SVG displacement mapping and WebGL refraction engine that accurately bends background pixels through glass edges.
• 📐 Smart Adaptive Sizing (Hug & Fixed): Auto-wraps content dynamically or allows fixed pixel dimensions (width / height).
• 🖐️ Bounded Pointer & Touch Drag Physics: Built-in multi-touch and pointer drag physics strictly clamped to window and viewport bounds.
• 🛡️ Zero DOM Conflict (Shadow DOM): Every instance encapsulates its styles and generates isolated SVG filter IDs — place unlimited glass elements on the same page with zero crosstalk.
• ⚡ 100% Framework Agnostic: Native Web Components standard with dedicated TypeScript wrappers for Vue 3, Nuxt 3, React, Next.js, Svelte, Astro, and Vanilla HTML5.
• 🎨 Deep Physics Customization: Tweak IOR (Index of Refraction), thickness, bezel width, backdrop blur, tint colors, specular lighting, and squircle curvature profiles in real-time.

---

📦 Installation

Install @ozcanyldzhn/liquid-glass-js using your favorite package manager:

# npm
npm install @ozcanyldzhn/liquid-glass-js

# pnpm
pnpm add @ozcanyldzhn/liquid-glass-js

# yarn
yarn add @ozcanyldzhn/liquid-glass-js

# bun
bun add @ozcanyldzhn/liquid-glass-js

---

🚀 Quick Start Guide

🟢 Vue 3 / Nuxt 3

Import the package and its stylesheet once in your application (main.ts or component). In Nuxt 3, wrap in <ClientOnly> for SSR safety.

<script setup>
import { ref } from 'vue';
import '@ozcanyldzhn/liquid-glass-js';
import '@ozcanyldzhn/liquid-glass-js/css';

const glassRef = ref(null);
</script>

<template>
  <ClientOnly>
    <!-- Draggable Glass Container -->
    <liquid-glass
      ref="glassRef"
      width="420"
      height="240"
      radius="36"
      thickness="90"
      bezel="50"
      ior="3.0"
      tint-opacity="4"
      draggable="true"
    >
      <div class="glass-content">
        <h2>Liquid Glass in Vue 3</h2>
        <p>Real-time optical refraction with custom displacement mapping.</p>
      </div>
    </liquid-glass>
  </ClientOnly>
</template>

<style scoped>
.glass-content {
  padding: 24px;
  color: #ffffff;
  display: flex;
  flex-direction: column;
  justify-content: center;
  height: 100%;
}
</style>

---

⚛️ React / Next.js (App & Pages Router)

Use the dedicated React wrapper with TypeScript definitions and full ref forwarding.

'use client';

import React, { useRef } from 'react';
import { LiquidGlassReact } from '@ozcanyldzhn/liquid-glass-js/react';
import '@ozcanyldzhn/liquid-glass-js/css';

export default function GlassCard() {
  const glassRef = useRef<HTMLElement | null>(null);

  return (
    <LiquidGlassReact
      ref={glassRef}
      width={420}
      height={240}
      radius={36}
      thickness={90}
      bezel={50}
      ior={3.0}
      tintOpacity={4}
      draggable={true}
    >
      <div style={{ padding: '24px', color: '#fff' }}>
        <h2>Liquid Glass in React</h2>
        <p>Interactive iOS 26 optics in React 18 & 19.</p>
      </div>
    </LiquidGlassReact>
  );
}

---

🌐 Vanilla HTML5 / JavaScript

No build tools required! Include the stylesheet and module script directly.

<!DOCTYPE html>
<html lang="en">
<head>
  <meta charset="UTF-8" />
  <title>Liquid Glass Demo</title>
  <link rel="stylesheet" href="https://unpkg.com/@ozcanyldzhn/liquid-glass-js/dist/liquid-glass.css">
  <script type="module" src="https://unpkg.com/@ozcanyldzhn/liquid-glass-js/dist/liquid-glass.js"></script>
</head>
<body style="min-height: 100vh; background: url('wallpaper.jpg') center/cover no-repeat;">

  <!-- Auto-Sizing Glass Button -->
  <liquid-glass radius="20" ior="2.6" draggable="true">
    <div style="padding: 10px 22px; font-weight: 600; color: #fff;">
      ✨ Auto-Sizing Button
    </div>
  </liquid-glass>

  <!-- Interactive Glass Card -->
  <liquid-glass width="400" height="230" radius="32" ior="3.0" thickness="90" bezel="50" draggable="true">
    <div style="padding: 24px; color: #fff;">
      <h3>🔮 Pure Glassmorphism</h3>
      <p>Bends background light vectors dynamically across the viewport.</p>
    </div>
  </liquid-glass>

</body>
</html>

---

🎛️ Multiple Independent Elements on One Page

You can place unlimited Liquid Glass components on the same webpage simultaneously.

Each <liquid-glass> element automatically:

• Generates a unique isolated SVG displacement filter (liquid-glass-filter-1, liquid-glass-filter-2, ...).
• Encapsulates rendering within its own Shadow DOM.
• Handles independent pointer drag physics and dimensions without interfering with neighboring glass elements.

<!-- Mini Glass Audio Pill -->
<liquid-glass radius="18" ior="2.4" thickness="55" tint-color="#06b6d4" tint-opacity="10" draggable="true">
  <div style="padding: 8px 16px; color: white;">🎵 Now Playing</div>
</liquid-glass>

<!-- High-Refraction Dashboard Card -->
<liquid-glass width="440" height="260" radius="36" ior="3.0" thickness="110" bezel="60" draggable="true">
  <div style="padding: 24px; color: white;">
    <h3>Deep Refraction Pane</h3>
  </div>
</liquid-glass>

---

📋 Props & Attributes Reference

Prop / Attribute	Type	Default	Description
width	number | string	auto	Element width in pixels. Omit for dynamic content-hugging auto sizing.
height	number | string	auto	Element height in pixels. Omit for dynamic content-hugging auto sizing.
radius	number | string	24	Border radius in pixels (auto-constrained to maximum squircle pill).
ior	number | string	3.0	Index of refraction / optical distortion strength (1.0–3.0).
thickness	number | string	80	Glass displacement thickness depth (10–200).
bezel	number | string	60	Refraction bezel edge width (5–100).
surface-fn	string	'convex_squircle'	Curvature profile: convex_squircle, convex_circle, concave, lip.
blur	number | string	0	Backdrop blur intensity in pixels.
tint-color	string	'#ffffff'	Hex color string for custom tinted glass (e.g. '#8b5cf6').
tint-opacity	number | string	0	Tint layer opacity percentage (0–100).
specular-opacity	number | string	0	Specular light reflection intensity (0.0–1.0).
outer-shadow-blur	number | string	24	Outer drop shadow elevation blur in pixels.
draggable	boolean	false	Enables smooth pointer & touch drag-and-drop physics with boundary constraints.
engine	string	'svg'	Optical rendering engine: 'svg' (Displacement Mapping) or 'webgl' (Raytracing).

---

🧪 Interactive Physics Studio & Local Development

Experience live optical parameter tweaking, card templates, and multi-framework code export in the interactive Physics Studio:

# 1. Clone repository
git clone https://github.com/ozcanyldzhn/liquid-glass.js.git
cd liquid-glass.js

# 2. Install dependencies
npm install

# 3. Start local development server
npm run dev

Visit http://localhost:5173/studio to:

• 🎛️ Dashboard: Test screen-bounded transparent draggable glass.
• 🌟 Showcase: Interactive audio wave synthesizer and weather widgets.
• 🧪 Physics Studio: Real-time 3-column optical workbench with instant Vue 3, React, and HTML5 code export.
• 📖 API Reference: High-contrast reference documentation.

---

🛠️ Build & Contribution

# Build NPM Library Package (dist/liquid-glass.js, .cjs, .css, .d.ts)
npm run build:lib

# Build Full Web Application for Production Deployment (Vercel)
npm run build

# Preview Production Build Locally
npm run preview

---

📄 License

MIT License © Özcan Yıldızhan
